Frejoth accessory catalogue · Page 224
BROWN & SHARPE TAPER END MILL HOLDER
Models on this page
CL-56-001CL-56-002CL-56-003CL-56-004CL-56-005CL-56-006CL-56-007CL-56-008CL-56-009CL-56-010CL-56-011CL-56-012CL-56-013CL-56-014CL-56-015CL-56-016CL-56-017CL-56-018CL-56-019CL-56-020CL-56-021CL-56-022CL-56-023CL-56-024CL-56-025CL-56-026CL-56-027CL-56-028CL-56-029CL-56-030CL-56-031CL-56-032CL-56-033CL-56-034CL-56-035CL-56-036CL-56-037CL-56-038CL-56-039CL-56-040CL-56-041CL-56-042CL-56-043CL-56-044CL-56-045CL-56-046CL-56-047CL-56-048CL-56-049CL-56-050CL-56-051CL-56-052CL-56-053CL-56-054CL-56-055CL-56-056CL-56-057CL-56-058CL-56-059CL-56-060CL-56-061CL-56-062
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
Brown & Sharpe Taper End Mill Holder
CL-56 · Taiwan
- Style "A"-Tang End.
- Style "B"-Threaded End for Drawbar
| order_no | b_s_taper | bore |
|---|---|---|
| CL-56-001 | #7 | 3/16" |
| CL-56-002 | #7 | 3/8" |
| CL-56-003 | #7 | 1/2" |
| CL-56-004 | #9 | 3/16" |
| CL-56-005 | #9 | 3/8" |
| CL-56-006 | #9 | 1/2" |
| CL-56-007 | #9 | 5/8" |
| CL-56-008 | #9 | 3/4" |
| CL-56-009 | #9 | 7/8" |
| CL-56-010 | #9 | 1" |
| CL-56-011 | #10 | 3/8" |
| CL-56-012 | #10 | 1/2" |
| CL-56-013 | #10 | 5/8" |
| CL-56-014 | #10 | 3/4" |
| CL-56-015 | #10 | 7/8" |
| CL-56-016 | #10 | 1" |
| CL-56-017 | #10 | 1-1/4" |
| CL-56-018 | #11 | 3/8" |
| CL-56-019 | #11 | 1/2" |
| CL-56-020 | #11 | 5/8" |
| CL-56-021 | #11 | 3/4" |
| CL-56-022 | #11 | 7/8" |
| CL-56-023 | #11 | 1" |
| CL-56-024 | #11 | 1-1/4" |
| CL-56-025 | #11 | 1-1/2" |
| CL-56-026 | #11 | 2" |
| CL-56-027 | #12 | 3/8" |
| CL-56-028 | #12 | 1/2" |
| CL-56-029 | #12 | 5/8" |
| CL-56-030 | #12 | 3/4" |
| CL-56-031 | #12 | 7/8" |
| CL-56-032 | #12 | 1" |
| CL-56-033 | #12 | 1-1/4" |
| CL-56-034 | #12 | 1-1/2" |
| CL-56-035 | #12 | 2" |
| Code | Model |
|---|---|
| CL-56-032 | CL-56-032 |
| CL-56-033 | CL-56-033 |
| CL-56-034 | CL-56-034 |
| CL-56-035 | CL-56-035 |
| CL-56-001 | CL-56-001 |
| CL-56-002 | CL-56-002 |
| CL-56-003 | CL-56-003 |
| CL-56-004 | CL-56-004 |
| CL-56-005 | CL-56-005 |
| CL-56-006 | CL-56-006 |
| CL-56-007 | CL-56-007 |
| CL-56-008 | CL-56-008 |
| CL-56-009 | CL-56-009 |
| CL-56-010 | CL-56-010 |
| CL-56-011 | CL-56-011 |
| CL-56-012 | CL-56-012 |
| CL-56-013 | CL-56-013 |
| CL-56-014 | CL-56-014 |
| CL-56-015 | CL-56-015 |
| CL-56-016 | CL-56-016 |
| CL-56-017 | CL-56-017 |
| CL-56-018 | CL-56-018 |
| CL-56-019 | CL-56-019 |
| CL-56-020 | CL-56-020 |
| CL-56-021 | CL-56-021 |
| CL-56-022 | CL-56-022 |
| CL-56-023 | CL-56-023 |
| CL-56-024 | CL-56-024 |
| CL-56-025 | CL-56-025 |
| CL-56-026 | CL-56-026 |
| CL-56-027 | CL-56-027 |
| CL-56-028 | CL-56-028 |
| CL-56-029 | CL-56-029 |
| CL-56-030 | CL-56-030 |
| CL-56-031 | CL-56-031 |
Two body styles illustrated: A-TYPE and B-TYPE. The table does not distinguish which order numbers are A-type vs B-type.
Brown & Sharpe Taper Shell End Mill Holder
CL-56 · Taiwan
| order_no | b_s_taper | dia_of_bore | dia_range_of_standard_end_mill |
|---|---|---|---|
| CL-56-036 | #7 | 1/2" | 1-1/4" to 1-1/2" |
| CL-56-037 | #7 | 3/4" | 1-3/4" to 2" |
| CL-56-038 | #7 | 1" | 2-1/4" to 2-3/4" |
| CL-56-039 | #9 | 1/2" | 1-1/4" to 1-1/2" |
| CL-56-040 | #9 | 3/4" | 1-3/4" to 2" |
| CL-56-041 | #9 | 1" | 2-1/4" to 2-3/4" |
| CL-56-042 | #9 | 1-1/4" | 3" to 3-1/2" |
| CL-56-043 | #9 | 1-1/2" | 4" to 5" |
| CL-56-044 | #9 | 2" | 5-1/2" to 6" |
| CL-56-045 | #10 | 1/2" | 1-1/4" to 1-1/2" |
| CL-56-046 | #10 | 3/4" | 1-3/4" to 2" |
| CL-56-047 | #10 | 1" | 2-1/4" to 2-3/4" |
| CL-56-048 | #10 | 1-1/4" | 3" to 3-1/2" |
| CL-56-049 | #10 | 1-1/2" | 4" to 5" |
| CL-56-050 | #10 | 2" | 5-1/2" to 6" |
| CL-56-051 | #11 | 1/2" | 1-1/4" to 1-1/2" |
| CL-56-052 | #11 | 3/4" | 1-3/4" to 2" |
| CL-56-053 | #11 | 1" | 2-1/4" to 2-3/4" |
| CL-56-054 | #11 | 1-1/4" | 3" to 3-1/2" |
| CL-56-055 | #11 | 1-1/2" | 4" to 5" |
| CL-56-056 | #11 | 2" | 5-1/2" to 6" |
| CL-56-057 | #12 | 1/2" | 1-1/4" to 1-1/2" |
| CL-56-058 | #12 | 3/4" | 1-3/4" to 2" |
| CL-56-059 | #12 | 1" | 2-1/4" to 2-3/4" |
| CL-56-060 | #12 | 1-1/4" | 3" to 3-1/2" |
| CL-56-061 | #12 | 1-1/2" | 4" to 5" |
| CL-56-062 | #12 | 2" | 5-1/2" to 6" |
| Code | Model |
|---|---|
| CL-56-036 | CL-56-036 |
| CL-56-037 | CL-56-037 |
| CL-56-038 | CL-56-038 |
| CL-56-039 | CL-56-039 |
| CL-56-040 | CL-56-040 |
| CL-56-041 | CL-56-041 |
| CL-56-042 | CL-56-042 |
| CL-56-043 | CL-56-043 |
| CL-56-044 | CL-56-044 |
| CL-56-045 | CL-56-045 |
| CL-56-046 | CL-56-046 |
| CL-56-047 | CL-56-047 |
| CL-56-048 | CL-56-048 |
| CL-56-049 | CL-56-049 |
| CL-56-050 | CL-56-050 |
| CL-56-051 | CL-56-051 |
| CL-56-052 | CL-56-052 |
| CL-56-053 | CL-56-053 |
| CL-56-054 | CL-56-054 |
| CL-56-055 | CL-56-055 |
| CL-56-056 | CL-56-056 |
| CL-56-057 | CL-56-057 |
| CL-56-058 | CL-56-058 |
| CL-56-059 | CL-56-059 |
| CL-56-060 | CL-56-060 |
| CL-56-061 | CL-56-061 |
| CL-56-062 | CL-56-062 |
Two body styles illustrated: A-TYPE (with separate cap screw) and B-TYPE.
