CLAMP PARALLEL SCREW

Taiwan

parallel_screw_clamps (mm)
item_no	span_x_depth_mm	jaw_length_mm	weight_kg	pack_pcs
PLC-028	28 x 16	50	0.09	50
PLC-040	40 x 25	60	0.15	50
PLC-055	55 x 35	75	0.25	50
PLC-070	70 x 50	100	0.45	20
PLC-105	105 x 70	150	0.9	20

cantilever_c_clamps (mm)
item_no	span_a_inch_mm	depth_b_mm	depth_c_mm	weight_kg	pressure_kg	pack_pcs
CTC-1	1"/25	15	20	0.06	130	50
CTC-2	2"/50	33	42	0.25	310	50
CTC-3	3"/75	35	49	0.52	500	20

Order references
Code	Model
on request	PLC-028
on request	PLC-040
on request	PLC-055
on request	PLC-070
on request	PLC-105
on request	CTC-1
on request	CTC-2
on request	CTC-3

Banner covers two distinct clamps: the PLC parallel screw clamp (span 16~70 mm drawing, jaw length) and an unheaded cantilever C-clamp range CTC-1~CTC-3 with span A / depth B / depth C drawings.

CANTILEVER C-CLAMP QUICK ADJUSTABLE

Taiwan

specifications (mm)
item_no	span_a_inch_mm	depth_b_mm	depth_c_mm	weight_kg	pressure_kg	pack_pcs
CTC-4.5	4.5"/110	58	78	0.8	680	20
CTC-6	6"/150	110	128	2	850	10

Order references
Code	Model
on request	CTC-4.5
on request	CTC-6

CANTILEVER CTC LIGHT

Taiwan

specifications (mm)
item_no	span_a_inch_mm	depth_b_mm	depth_c_mm	weight_kg	pressure_kg	pack_pcs
CTC-2-AL	2"/50	33	42	0.1	200	50

Order references
Code	Model
on request	CTC-2-AL
