FMS Flexible Balance Gripper Jaw Power Vise
Models on this page
FB-100FB-1000FB-130FB-160FB-200FB-250FB-511FFB-511FRFB-511RFB-519FFB-519RFB-524FFB-524RFB-525HFFB-525HRFB-550HFFB-550HRFB-550SFFB-550SRFM-100FM-130FM-160FM-200FM-250VQV-100V-FBVQV-100V-FMVQV-130V-FBVQV-130V-FMVQV-160V-FBVQV-160V-FMVQV-200V-FBVQV-200V-FMVQV-250V-FBVQV-250V-FM
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
FMS Flexible Balance Gripper Jaw Power Vise
FMS·Power · Taiwan
| order_no | model | a | b | c | d | e | j | j1 | k | n | x | y | limit_pressure | n_w | g_w | shipment_size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10220100 | VQV-100V-FB | 406 | 300 | 106 | 101 | 160 | 100 | 220 | 22 | 18 | 51 | 85 | 41KN(4018kgf) | 18.5 | 20.5 | 590x175x185 |
| 10220130 | VQV-130V-FB | 516 | 410 | 106 | 131 | 190 | 180 | 320 | 22 | 18 | 60 | 95 | 45KN(4410kgf) | 33.5 | 35.5 | 665x190x225 |
| 10220160 | VQV-160V-FB | 581 | 475 | 106 | 161 | 220 | 220 | 380 | 22 | 18 | 64 | 105 | 54KN(5296kgf) | 51.5 | 54.5 | 760x190x215 |
| 10220200 | VQV-200V-FB | 661 | 555 | 106 | 201 | 260 | 250 | 460 | 22 | 18 | 90 | 110 | 66KN(6466kgf) | 80 | 83 | 820x230x220 |
| 10220250 | VQV-250V-FB | 903 | 805 | 106 | 251 | 310 | 450 | 700 | 22 | 22 | 276.5 | 115 | 70KN(6860kgf) | 143 | 159 | 1045x410x330 |
| 10222100 | VQV-100V-FM | 406 | 300 | 106 | 101 | 160 | 150 | 220 | 22 | 18 | 51 | 85 | 41KN(4018kgf) | 17.5 | 19.5 | 590x175x185 |
| 10222130 | VQV-130V-FM | 516 | 410 | 106 | 131 | 190 | 210 | 320 | 22 | 18 | 60 | 95 | 45KN(4410kgf) | 32.5 | 34.5 | 665x190x225 |
| 10222160 | VQV-160V-FM | 581 | 475 | 106 | 161 | 220 | 280 | 380 | 22 | 18 | 64 | 105 | 54KN(5296kgf) | 52.5 | 55.5 | 760x190x215 |
| 10222200 | VQV-200V-FM | 661 | 555 | 106 | 201 | 260 | 320 | 460 | 22 | 18 | 90 | 110 | 66KN(6466kgf) | 76.5 | 79.5 | 820x230x220 |
| 10222250 | VQV-250V-FM | 903 | 805 | 106 | 251 | 310 | 550 | 700 | 22 | 22 | 276.5 | 115 | 70KN(6860kgf) | 141 | 157 | 1045x410x330 |
| Code | Model |
|---|---|
| 10220100 | VQV-100V-FB |
| 10220130 | VQV-130V-FB |
| 10220160 | VQV-160V-FB |
| 10220200 | VQV-200V-FB |
| 10220250 | VQV-250V-FB |
| 10222100 | VQV-100V-FM |
| 10222130 | VQV-130V-FM |
| 10222160 | VQV-160V-FM |
| 10222200 | VQV-200V-FM |
| 10222250 | VQV-250V-FM |
Gripper Sets ref. P140. Clamp force scale on page indicates approximately 40-75 KN. Models VQV-...-FB (flexible balance) and VQV-...-FM (flexible movable).
Stationary & Balance Jaw (Hardened)
Taiwan
| order_no | model | stationary_jaw | bolts | plug | balance_jaw | bolts_2 | plug_2 |
|---|---|---|---|---|---|---|---|
| 10260100 | FB-100 | FB-100Ax1 | M10x25Lx4 | 8 | FB-100Bx1 | M10x25Lx4 | 6 |
| 10260130 | FB-130 | FB-130Ax1 | M12x30Lx4 | 8 | FB-130Bx1 | M12x30Lx4 | 8 |
| 10260160 | FB-160 | FB-160Ax1 | M14x30Lx4 | 8 | FB-160Bx1 | M14x30Lx4 | 8 |
| 10260200 | FB-200 | FB-200Ax1 | M16x35Lx4 | 12 | FB-200Bx1 | M16x35Lx4 | 10 |
| 10260250 | FB-250 | FB-250Ax1 | M16x45Lx4 | 12 | FB-250Bx1 | M16x40Lx4 | 12 |
| Code | Model |
|---|---|
| 10260100 | FB-100 |
| 10260130 | FB-130 |
| 10260160 | FB-160 |
| 10260200 | FB-200 |
| 10260250 | FB-250 |
Illustrated as FB-160A (stationary jaw) and FB-160B (balance jaw). Both jaw columns are listed under the heading 'Standard Accessories'.
Stationary & Movable Jaw (Hardened)
Taiwan
| order_no | model | stationary_jaw | bolts | plug | movable_jaw | bolts_2 | plug_2 |
|---|---|---|---|---|---|---|---|
| 10280100 | FM-100 | FB-100Ax1 | M10x25Lx4 | 8 | FB-100Cx1 | M10x25Lx4 | 6 |
| 10280130 | FM-130 | FB-130Ax1 | M12x30Lx4 | 8 | FB-130Cx1 | M12x30Lx4 | 8 |
| 10280160 | FM-160 | FB-160Ax1 | M14x30Lx4 | 8 | FB-160Cx1 | M14x30Lx4 | 8 |
| 10280200 | FM-200 | FB-200Ax1 | M16x35Lx4 | 12 | FB-200Cx1 | M16x35Lx4 | 10 |
| 10280250 | FM-250 | FB-250Ax1 | M16x45Lx4 | 15 | FB-250Cx1 | M16x40Lx4 | 10 |
| Code | Model |
|---|---|
| 10280100 | FM-100 |
| 10280130 | FM-130 |
| 10280160 | FM-160 |
| 10280200 | FM-200 |
| 10280250 | FM-250 |
Illustrated as FB-160A (stationary jaw) and FB-160C (movable jaw). Both jaw columns are listed under the heading 'Standard Accessories'.
Gripper Sets
FB-1000 · Taiwan
| order_no | model | thread |
|---|---|---|
| 10290002 | FB-525HF | M12x35L |
| 10290004 | FB-525HR | M12x35L |
| 10290006 | FB-550HF | M12x60L |
| 10290008 | FB-550HR | M12x60L |
| 10290010 | FB-550SF | M12x70L |
| 10290012 | FB-550SR | M12x70L |
| 10290022 | FB-511F | M12x30L |
| 10290024 | FB-511R | M12x30L |
| 10290026 | FB-519F | M12x30L |
| 10290028 | FB-519R | M12x30L |
| 10290030 | FB-524F | M12x30L |
| 10290032 | FB-524R | M12x30L |
| 10290034 | FB-511FR | M12x30L |
| Code | Model |
|---|---|
| 10290002 | FB-525HF |
| 10290004 | FB-525HR |
| 10290006 | FB-550HF |
| 10290008 | FB-550HR |
| 10290010 | FB-550SF |
| 10290012 | FB-550SR |
| 10290022 | FB-511F |
| 10290024 | FB-511R |
| 10290026 | FB-519F |
| 10290028 | FB-519R |
| 10290030 | FB-524F |
| 10290032 | FB-524R |
| 10290034 | FB-511FR |
| on request | FB-1000 |
FB-1000 set contains (FB-511F, 511R, 519F, 519R, 524F, 524R, 511FR, 550HR, 550SF, 550SR, 525HF, 525HR, 550HF) x 4 pcs. No order number is printed for the FB-1000 set itself; only for the 13 individual grippers, each supplied as 4 pcs per the photographs.
