GROUND PARALLELS
Models on this page
JC-32-017JC-32-027AJC-32-027BJC-32-028JC-32-029JC-32-030JC-32-031JC-32-032JC-32-033JC-32-034JC-32-035JC-32-036JC-32-037JC-32-038JC-32-039JC-32-040JC-32-041JC-32-042JC-32-043JC-32-044
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
GROUND PARALLELS
JC-32-017 · TAIWAN
- Material : S45C
- Haroness : HRC 50°-55°
- N.W. : 11 kgs
| w_x_h_x_l_x_pcs |
|---|
| 5 x 16 x 100 x 2 |
| 6 x 18 x 100 x 2 |
| 8 x 24 x 100 x 2 |
| 10 x 30 x 100 x 2 |
| 12 x 36 x 150 x 2 |
| 14 x 48 x 150 x 2 |
| 18 x 60 x 150 x 2 |
| 22 x 62 x 150 x 2 |
| 31 x 15 x 200 x 2 x 2.5 |
| Code | Model |
|---|---|
| JC-32-017 | JC-32-017 |
Set contents listed as W x H x L x PCS in two side-by-side columns; the two columns are one continuous list.
UNIVERSAL ANGLE BLOCK SET
JC-32-027A.B · TAIWAN
| order_no | w_x_h_x_l | n_w_kg |
|---|---|---|
| JC-32-027A | 1-3/16" x 1-3/16" x 3" | 1.8 |
| JC-32-027B | 1-1/2" x 1-1/2" x 4" | 3.6 |
| Code | Model |
|---|---|
| JC-32-027A | JC-32-027A |
| JC-32-027B | JC-32-027B |
Dimension drawing shows 7°, 3° and 10° angle blocks.
PARALLELS
JC-32-028 · TAIWAN
- Made of high grade tool steel. hardened and precision ground to very close tolerances on 4 sides. Parallels are finished, packed and sold in pairs. Tolerance is within ±0.0002"
| order_no | w_x_h_x_l_x_pcs | n_w_kg |
|---|---|---|
| JC-32-028 | 1/4 x 1/2 x 6 x 2 | 0.2 |
| JC-32-029 | 1/4 x 5/8 x 6 x 2 | 0.25 |
| JC-32-030 | 1/4 x 3/4 x 6 x 2 | 0.3 |
| JC-32-031 | 3/8 x 1/2 x 6 x 2 | 0.3 |
| JC-32-032 | 3/8 x 3/4 x 6 x 2 | 0.44 |
| JC-32-033 | 1/2 x 3/4 x 6 x 2 | 0.58 |
| JC-32-034 | 1/2 x 1 x 6 x 2 | 0.8 |
| JC-32-035 | 1/2 x 3/4 x 9 x 2 | 0.87 |
| JC-32-036 | 1/2 x 1 x 9 x 2 | 1.2 |
| JC-32-037 | 3/4 x 1 x 9 x 2 | 1.8 |
| JC-32-038 | 3/4 x 1 x 12 x 2 | 2.4 |
| JC-32-039 | 3/4 x 1-1/4 x 12 x 2 | 2.9 |
| JC-32-040 | 1 x 2 x 12 x 2 | 6.4 |
| JC-32-041 | 1-1/4 x 1-1/2 x 12 x 2 | 5.7 |
| JC-32-042 | 1-1/4 x 2 x 12 x 2 | 7.7 |
| JC-32-043 | 1-1/2 x 2 x 12 x 2 | 10.9 |
| JC-32-044 | 1-1/2 x 3 x 12 x 2 | 16.4 |
| Code | Model |
|---|---|
| JC-32-028 | JC-32-028 |
| JC-32-029 | JC-32-029 |
| JC-32-030 | JC-32-030 |
| JC-32-031 | JC-32-031 |
| JC-32-032 | JC-32-032 |
| JC-32-033 | JC-32-033 |
| JC-32-034 | JC-32-034 |
| JC-32-035 | JC-32-035 |
| JC-32-036 | JC-32-036 |
| JC-32-037 | JC-32-037 |
| JC-32-038 | JC-32-038 |
| JC-32-039 | JC-32-039 |
| JC-32-040 | JC-32-040 |
| JC-32-041 | JC-32-041 |
| JC-32-042 | JC-32-042 |
| JC-32-043 | JC-32-043 |
| JC-32-044 | JC-32-044 |
Drawing notes parallelism tolerances by length: 6" .0002", 9" .0003", 12" .0004".
