Power H Type Dovetail Slide Table

STZ · Taiwan

Order references
Code	Model
STZ-2050	STZ-2050

Only STZ-2050 is shown. No specification table is printed — the only dimensions are unlabelled callouts on the end-view drawing: overall width 200, 170 between feet, 16 slot, 125 upper width, overall height 150 (split 25 / 45 / 25), Ø62 hydraulic cylinder bore, 70 and 5.5 on the base.

Economic V Type Slide Table

STB · Taiwan

A. Material: over FC-30.
B. Precision: 0.01MM(300L).
C. Feature: The sliding surfaces are treated by Heat-treatment & precision grind.

stb_dimensions (mm)
model	a_x_b_table_surface	c_x_d_base_area	e	f	g	k	i	height	stroke	weight_kg
STB-1630	160x200	160x300	20	70	17	20	92	90	100	19
STB-1640	160x200	160x400	20	70	17	20	92	90	200	23
STB-2030	200x300	200x300	30	90	20	20	120	120	50	34
STB-2040	200x300	200x400	30	90	20	20	120	120	100	40
STB-2060	200x300	200x600	30	90	20	20	120	120	300	48
STB-2080	200x300	200x800	30	90	20	20	120	120	500	58
STB-20100	200x300	200x1000	30	90	20	20	120	120	700	69

Order references
Code	Model
STB-1630	STB-1630
STB-1640	STB-1640
STB-2030	STB-2030
STB-2040	STB-2040
STB-2060	STB-2060
STB-2080	STB-2080
STB-20100	STB-20100

Power H Type Slide Table

STC · Taiwan

A. Material: over FC-30.
B. Precision: 0.01MM(300L).
C. Feature: The sliding surfaces are treated by Heat-treatment & precision grind.
Optional accessories: Hand wheel.

stc_dimensions (mm)
model	a_x_b_table_surface	c_x_d_base_area	e	f	g	k	i	h	hydraulic_cylinder	weight_kg
STC-2040	200x300	200x400	30	120	20	25	120	150	Ø58	48
STC-2050	200x300	200x500	30	120	20	25	120	150	Ø58	52
STC-2060	200x300	200x600	30	120	20	25	120	150	Ø58	58
STC-2070	200x300	200x700	30	120	20	25	120	150	Ø58	64
STC-20130	200x300	200x1300	30	120	20	25	120	150	Ø58	95
STC-2552	250x360	250x520	35	127	25	28	150	162	Ø62	90
STC-2567	250x420	250x670	35	127	25	28	150	162	Ø62	95
STC-2575	250x420	250x750	35	127	25	28	150	162	Ø62	110
STC-3042	300x300	300x420	35	127	25	28	200	162	Ø62	100
STC-3056	300x360	300x560	35	127	25	28	200	162	Ø62	120
STC-3067	300x420	300x670	35	127	25	28	200	162	Ø62	130
STC-3050	300x350	300x500	39	149	27	28	212	188	Ø62	98
STC-3070	300x350	300x700	39	149	27	28	212	188	Ø62	120
STC-3080	300x350	300x800	39	149	27	28	212	188	Ø62	135
STC-30100	300x350	300x1000	39	149	27	28	212	188	Ø62	145
STC-30120	300x350	300x1200	39	149	27	28	212	188	Ø62	175
STC-30150	300x350	300x1500	39	149	27	28	212	188	Ø62	188
STC-30200	300x350	300x2000	39	149	27	28	212	188	Ø62	330
STC-30220	300x350	300x2200	39	149	27	28	212	188	Ø62	360
STC-4070	400x500	400x700	40	160	30	35	294	200	Ø72	205
STC-40100	400x500	400x1000	40	160	30	35	294	200	Ø72	245
STC-40130	400x500	400x1300	40	160	30	35	294	200	Ø72	285
STC-40160	400x500	400x1600	40	160	30	35	294	200	Ø72	325
STC-40200	400x500	400x2000	40	160	30	35	294	200	Ø72	380
STC-50120	500x600	500x1200	50	170	35	35	370	220	Ø90	450
STC-50150	500x600	500x1500	50	170	35	35	370	220	Ø90	520

Order references
Code	Model
STC-2040	STC-2040
STC-2050	STC-2050
STC-2060	STC-2060
STC-2070	STC-2070
STC-20130	STC-20130
STC-2552	STC-2552
STC-2567	STC-2567
STC-2575	STC-2575
STC-3042	STC-3042
STC-3056	STC-3056
STC-3067	STC-3067
STC-3050	STC-3050
STC-3070	STC-3070
STC-3080	STC-3080
STC-30100	STC-30100
STC-30120	STC-30120
STC-30150	STC-30150
STC-30200	STC-30200
STC-30220	STC-30220
STC-4070	STC-4070
STC-40100	STC-40100
STC-40130	STC-40130
STC-40160	STC-40160
STC-40200	STC-40200
STC-50120	STC-50120
STC-50150	STC-50150

Series shown as STC-20 / STC-25 / STC-30 / STC-40 / STC-50.
