PRECISION PARALLELS
Models on this page
JC-31-001JC-31-012JC-31-022JC-31-031JC-32-001JC-32-013JC-32-014JC-32-015JC-32-016
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
PRECISION PARALLELS
JC-31-001 · TAIWAN
| order_no | net_weight | w_x_h_x_l_x_pcs |
|---|---|---|
| JC-31-001 | N.W. 3 kg | 3 x 13 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 16 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 19 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 22 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 25 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 28 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 31 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 35 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 38 x 150 x 2 |
| JC-31-001 | N.W. 3 kg | 3 x 41 x 150 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 10 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 14 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 18 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 22 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 26 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 30 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 34 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 38 x 100 x 2 |
| JC-31-012 | N.W. 1.9 kg | 4 x 42 x 100 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 12 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 17 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 22 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 25 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 28 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 32 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 36 x 120 x 2 |
| JC-31-022 | N.W. 3.8 kg | 8 x 38 x 120 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 17 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 22 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 25 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 28 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 32 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 36 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 38 x 200 x 2 |
| JC-31-031 | N.W. 6.6 kg | 8 x 43 x 200 x 2 |
| Code | Model |
|---|---|
| on request | JC-31-001 |
| on request | JC-31-012 |
| on request | JC-31-022 |
| on request | JC-31-031 |
Material : S45C. Haroness : HRC 50°-55°. Four boxed sets are listed, each with its own net weight. Flatness callout on the drawing is 0.005 H.
1/8"THIN STYLE PARALLELS SET
JC-32-001 · TAIWAN
| w_x_h_x_l_x_pcs | hole |
|---|---|
| 1/8 x 1/2 x 6 x 2 | 1/4 |
| 1/8 x 5/8 x 6 x 2 | 1/4 |
| 1/8 x 3/4 x 6 x 2 | 5/16 |
| 1/8 x 7/8 x 6 x 2 | 5/16 |
| 1/8 x 1 x 6 x 2 | 5/16 |
| 1/8 x 1-1/8 x 6 x 2 | 3/8 |
| 1/8 x 1-1/4 x 6 x 2 | 3/8 |
| 1/8 x 1-3/8 x 6 x 2 | 1/2 |
| 1/8 x 1-1/2 x 6 x 2 | 1/2 |
| 1/8 x 1-5/8 x 6 x 2 | 1/2 |
| Code | Model |
|---|---|
| on request | JC-32-001 |
Material : S45C. Haroness : HRC 50°-55°. N.W. : 3.5 kg. Parallelism callout on the drawing is .0002".
PRECISION PARALLELS SET
JC-32-012 · TAIWAN
- Set of 4 pairs of hardened and ground parallels. 1",1-1/4",1-1/2",1-3/4" in height x 6" long, with 5/16 thru and 1/2 holes.
- The 1" and 1-1/4" parallels are 3/16" thick. The 1-1/2" and 1-3/4" parallels are 1/2" thick. For setting up work for drilling and measuring. With wooden case.
| order_no | w_x_h_x_l_x_pcs | hole |
|---|---|---|
| JC-32-013 | 3/16 x 1 x 6 x 2 | 5/16 |
| JC-32-014 | 3/16 x 1-1/4 x 6 x 2 | 5/16 |
| JC-32-015 | 1/2 x 1-1/2 x 6 x 2 | 1/2 |
| JC-32-016 | 1/2 x 1-3/4 x 6 x 2 | 1/2 |
| Code | Model |
|---|---|
| on request | JC-32-013 |
| on request | JC-32-014 |
| on request | JC-32-015 |
| on request | JC-32-016 |
Material : S45C. Haroness : HRC 50°-55°. N.W. : 3.3 kgs. Parallelism callout on the drawing is .0002".
