V-BLOCK AND CLAMPS
Models on this page
JC-34-001JC-34-002JC-34-003JC-34-004JC-34-005JC-34-006JC-34-007JC-34-008JC-34-009JC-34-010JC-34-011JC-34-013JC-34-014JC-34-015JC-34-016JC-34-017
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
V-BLOCK AND CLAMPS
JC-34-001~005 · TAIWAN
| order_no | w_x_h_x_l_x_pcs | capacity | n_w_kg |
|---|---|---|---|
| JC-34-001 | 40 x 30 x 50 mm (1.57 x 1.18 x 1.96") x 2 | 30 mm | 1 |
| JC-34-002 | 50 x 40 x 50 mm (1.96 x 1.57 x 2.36") x 2 | 40 mm | 1.5 |
| JC-34-003 | 60 x 50 x 70 mm (2.36 x 1.86 x 2.75") x 2 | 50 mm | 2.3 |
| JC-34-004 | 41 x 35 x 44 mm (1.61 x 1.37 x 1.73") x 2 | 25 mm | 1 |
| JC-34-005 | 44 x 41 x 70 mm (1.73 x 1.61 x 2.75") x 2 | 30 mm | 1.8 |
| Code | Model |
|---|---|
| JC-34-001 | JC-34-001 |
| JC-34-002 | JC-34-002 |
| JC-34-003 | JC-34-003 |
| JC-34-004 | JC-34-004 |
| JC-34-005 | JC-34-005 |
| JC-34-006 | JC-34-006 |
| JC-34-007 | JC-34-007 |
| JC-34-008 | JC-34-008 |
| JC-34-009 | JC-34-009 |
| JC-34-010 | JC-34-010 |
| JC-34-011 | JC-34-011 |
Spec block: Material : S45C / Accuracy : 0.01 mm / Haroness : 50°-60°. Photos labelled JC-34-001, JC-34-002, JC-34-003 and JC-34-004/JC-34-005.
V-BLOCK AND CLAMPS
JC-34-006~011 · TAIWAN
| order_no | w_x_h_x_l_x_pcs | capacity | n_w_kg |
|---|---|---|---|
| JC-34-006 | 2-1/2" x 1-3/4" x 2-3/4" x 2 | 1-3/16 | 2.4 |
| JC-34-007 | 3-1/2" x 2-3/4" x 4-7/8" x 2 | 1-3/8 | 10 |
| JC-34-008 | 2-1/2" x 2" x 2-1/2" x 1 | 1-3/8 | 1.4 |
| JC-34-009 | 4" x 3" x 3" x 1 | 2-1/4 | 4 |
| JC-34-010 | 6" x 4" x 6" x 1 | 4-3/8 | 13.5 |
| JC-34-011 | 6" x 6" x 6" x1 | 4-3/8 | 24 |
Two spec blocks. Order No. : JC-34-006.007.008.009 — Material : S45C / Accuracy : 0.01 mm / Haroness : 50°-55°. Order No. : JC-34-010.011 — Material : S45C / Accuracy : 0.015 mm / Haroness : 45°-50°. Photos labelled JC-34-006/JC-34-007, JC-34-008/JC-34-009, JC-34-010 and JC-34-011.
PRECISION ANGLE PLATE
JC-34-013 · TAIWAN
- Parallelism : Within 0.003 mm / 100 mm
- Sqareness : Within 0.005 mm / 100 mm
| order_no | a | b | c | d | n_w_kg |
|---|---|---|---|---|---|
| JC-34-013 | 73 | 73 | 100 | 25 | 2.5 |
| JC-34-014 | 100 | 100 | 100 | 25 | 3.4 |
| JC-34-015 | 100 | 100 | 150 | 25 | 4.5 |
| JC-34-016 | 200 | 120 | 200 | 40 | 13 |
| JC-34-017 | 300 | 150 | 300 | 50 | 34 |
| Code | Model |
|---|---|
| JC-34-013 | JC-34-013 |
| JC-34-014 | JC-34-014 |
| JC-34-015 | JC-34-015 |
| JC-34-016 | JC-34-016 |
| JC-34-017 | JC-34-017 |
Drawing shows a tapped hole pattern marked 1/4"x20 with dimensions A (width), B (base depth), C (height) and D (plate thickness).
