Frejoth accessory catalogue · Page 246
YET-C AUTOMATIC RESISTANCE LUBRICATOR
Models on this page
YAEYAKYET-C1YET-C1P1YET-C2YET-C2P2
Get in touch about this product
Send us your details and we'll come back with pricing, availability and specifications.
YET-C AUTOMATIC RESISTANCE LUBRICATOR
YET-C · TAIWAN
- The float switch alarms and output signal when the oil level is low.
- The over temperature/load protector is attached to protect the motor.
- The function of fixed pressure for the pressure relief valve can prolong the system life.
- The indicator on the panel can display the operation of the lubricator.
- "Feed" key can force the lubricator to function. (incorporate with PLC control system)
| model_no | voltage_single_phase | consumption_power_w | output_power_w | capacity_of_terminal_output | lubrication_time | intermittent_time | output_bore | max_output_pressure_mpa_kgf_cm2 | output_volume_cc_min | pressure_release_device | float_switch | pressure_switch_kgf_cm2 | pressure_gauge | alarm_beeper | tank_capacity | weight_kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| YET-C2 | 110V/60Hz or 220V/60Hz | 100 | 11 | 0.3A (Float Switch), 3A (Pressure Switch) | Cooperate with PLC control system | Cooperate with PLC control system | Ø4 or Ø6 | 1.5 (15) | 150 | O | O (NC) | X | O | X | 3L | 2.8 |
| YET-C2P2 | 110V/60Hz or 220V/60Hz | 100 | 11 | 0.3A (Float Switch), 3A (Pressure Switch) | Cooperate with PLC control system | Cooperate with PLC control system | Ø4 or Ø6 | 1.5 (15) | 150 | O | O (NC) | 12-9 | O | X | 3L | 2.8 |
| YET-C1 | 110V/60Hz or 220V/60Hz | 80 | 8 | 0.3A (Float Switch), 3A (Pressure Switch) | Cooperate with PLC control system | Cooperate with PLC control system | Ø4 or Ø6 | 0.5 (5) | 200 | X | O (NC) | X | O | X | 4L (Metal Tank) | 3.5 |
| YET-C1P1 | 110V/60Hz or 220V/60Hz | 80 | 8 | 0.3A (Float Switch), 3A (Pressure Switch) | Cooperate with PLC control system | Cooperate with PLC control system | Ø4 or Ø6 | 0.5 (5) | 200 | X | O (NC) | 2.5-1.9 | O | X | 4L (Metal Tank) | 3.5 |
| Code | Model |
|---|---|
| on request | YET-C2 |
| on request | YET-C2P2 |
| on request | YET-C1 |
| on request | YET-C1P1 |
Photographs captioned YET-C-3L and YET-C-4L (Metal Tank). Dimension drawings shown for both bodies: (227) / 190~205 / (170) / (90) / (275) for the 3L body and (310) / 233~284 / (185) / (90) / (273) for the 4L body.
YAK/YAE AUTOMATIC LUBRICATOR
YAK/YAE · TAIWAN
- With temperature protection device for long term operation.
- Three operation modes as, (a) Lubrication: The lubricator runs via lubrication time after power-on. (b) Intermittence: The lubricator runs via intermittent time after power-on. (c) Memory: The lubricator runs via the previous set after power-on.
- Lubrication and intermittent time can be adjusted.
- The float switch alarms and output signal when the oil level is low.
- The function of fixed pressure for the pressure relief valve can prolong the system life.
- Lubrication time (second/minute) and intermittent time (second/minute/hour/cycle) are adjustable.
- The indicator on the panel can display the operation of the lubricator.
- The intermittent period can be adjusted via the machine's action cycles.
- "RES" key can force the lubricator to function.
- The motor is of long-time operation.
| model_no | voltage_single_phase | consumption_power_w | output_power_w | capacity_of_terminal_output | lubrication_time_second_minute | intermittent_time_second_minute_hour_cycle | output_bore | max_output_pressure_mpa_kgf_cm2 | output_volume_cc_min | pressure_release_device | float_switch | pressure_switch_kgf_cm2 | pressure_gauge | alarm_beeper |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| YAK | 110V/60Hz or 220V/60Hz | 56 | 25 | DC/AC 250V 3A | 1-999 | 1-999 | Ø4 or Ø6 | 2 (20) | 150 | O | O | X (Option) | O | O |
| YAE | 110V/60Hz or 220V/60Hz | 56 | 25 | DC/AC 250V 3A | 1-999 | 1-999 | Ø4 or Ø6 | 1 (10) | 150 (Standard) 250(Option) or 400(Option) | X | O | X (Option) | O | O |
| model_no | tank_capacity | weight_kg |
|---|---|---|
| YAK | 3L | 3.5 |
| YAK | 4L (Metal Tank) | 5.2 |
| YAE | 8L | 9.4 |
| YAE | 20L | 18 |
| Code | Model |
|---|---|
| on request | YAK |
| on request | YAE |
Photographs captioned YAK/YAE-3L (Inside-Adjust Type) and YAK/YAE-4L (Metal Tank). Dimension drawings shown for both bodies: (230) / 200~210 / (145) / (117) / (310) for the 3L body and (310) / 233~284 / (185) / (303) for the 4L body.
